Victron MultiPlus 48/3000/35-50 230V VE.Bus

The Victron MultiPlus 48/3000/35-50 230V VE.Bus is a versatile and efficient power solution that combines the functions of an inverter and charger in a single, streamlined package. True to its name, it offers a true sine wave inverter, ensuring high-quality and reliable power output.

With adaptive charging capabilities, the MultiPlus 48/3000/35-50 adjusts the charging process based on the battery’s condition and requirements, optimizing the charging efficiency and extending battery life.

One of its standout features is the hybrid PowerAssist technology, which intelligently manages power sources to prevent overload. This technology allows the MultiPlus to supplement the AC power from a limited source, such as a generator or shore power connection, with power drawn from the battery. This ensures a smooth and uninterrupted power supply without straining the limited AC source.

Furthermore, the MultiPlus 48/3000/35-50 offers a range of system integration features, making it compatible with various energy systems and enabling seamless integration into existing setups.

Overall, the Victron MultiPlus 48/3000/35-50 230V VE.Bus is a reliable and feature-rich solution that provides efficient and high-performance power conversion and charging capabilities for a wide range of applications.

Product Specifications

MULTIPLUS48/3000/35
PowerControlYes
PowerAssistYes
Transfer switch (A)16 or 50
INVERTER
Input voltage range (V DC)9,5 – 17 V
19 – 33 V
38 – 66 V
OutputOutput voltage: 230 VAC ± 2%
Frequency: 50 Hz ± 0,1%
Cont. output power at 25°C (VA)3000
Cont. output power at 25°C (W)2400
Cont. output power at 40°C (W)2200
Cont. output power at 65°C (W)1700
Peak power (W)6000
Maximum efficiency (%)93 / 94 / 95
Zero load power (W)20 / 20 / 25
Zero load power in AES mode (W)15 / 15 / 20
Zero load power in Search mode (W)8 / 10 / 12
CHARGER
AC InputInput voltage range: 187-265 VAC
Input frequency: 45 – 65 Hz
Power factor: 1
Charge voltage ‘absorption’ (V DC)14,4 / 28,8 / 57,6
Charge voltage ‘float’ (V DC)13,8 / 27,6 / 55,2
Storage mode (V DC)13,2 / 26,4 / 52,8
Charge current house battery (A)120 / 70 / 35
Charge current starter battery (A)4 (12 V and 24 V models only)
Battery temperature sensoryes
GENERAL
Auxiliary outputYes (16A)
Programmable relayYes
Protectiona – g
VE.Bus communication portFor parallel and three phase operation, remote monitoring and system integration
General purpose com. portYes
Remote on-offYes
Common CharacteristicsOperating temp. range: -40 to +65°C (fan assisted cooling)
Humidity (non-condensing): max 95%
ENCLOSURE
Common CharacteristicsMaterial & Colour: aluminium (blue RAL 5012)
Protection category: IP 21
Battery-connectionFour M8 bolts (2 plus and 2 minus connections)
230 V AC-connectionScrew terminals 13mm2 (6 AWG)
Weight (kg)18
Dimensions (hxwxd in mm)362 x 258 x 218
STANDARDS
SafetyEN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1
Emission, ImmunityEN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3,
IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Road vehicles12V and 24V models: ECE R10-4
Anti-islandingSee our website
